3,100lbs Sling 2-Ply

Single Layer Synethetic Web Sling,
Capacidade: 1,600lbs
Cor: Yellow
Size: 1"
Working Length:4' to 30'
SF: 5:1
HS: 6307
Brand: GANDA ou OEM

-Double Layer Synethetic Web Sling ASME/ANSI B.30.9

1" X 3.100LBS

GANDA (G&A) Web slings are a type of synthetic lifting sling that are typically made from 100% polyester webbing material. Synthetic web slings are some of the most common pieces of rigging equipment that you’ll find at any job site because they’re strong enough to support heavy loads, yet are extremely versatile and can be used effectively for a variety of different applications.

Web slings are popular in construction and other general industries because they offer the following advantages compared to traditional wire rope slings or alloy chain slings:

Inexpensive and lightweight design makes them attractive to almost any industry or lifting application

Made of soft, flexible materials that grip and mold to the shape of irregular loads

Strong enough to lift heavy loads but will protect expensive and delicate loads from scratching and crushing

A variety of materials, construction, and specifications can tailor synthetic web slings to almost any lifting application

Constructed from non-sparking and non-conductive fibers, so they can be used in explosive atmospheres


Temperature

Polyester web slings shall not be used in contact with an object or at temperatures in excess of 194°F (90°C) or below -40°F (-40°C).

Chemically Active Environments

The strength of synthetic web slings may be degraded by chemically active environments. This includes exposure to chemicals in the form of solids, liquids, gases, vapors, or fumes. The sling manufacturer or qualified person should be consulted before slings are used in chemically active environments.



CodeWidthLayer
Working Load Limit
Straight

Lift

Choked

Lift

ß
0°-7°7°-45°  45°-60°  Up to 45°   45°-60°
 1.0 0.82.0  1.4 1.0 0.7 0.5
GA-1-98011" 1 1600 12803200

2240

16001120800
GA-1-98022"1 3100248062004340310021701550
GA-2-98011" 2 3100248062004340310021701550
GA-2-98022"2 62004960124008680620043403100
GA-2-98033" 2 880070401760012320880061604400
GA-2-98044"2 11000880022000154001100077005500
GA-2-98055"2137001096027400191801370095906850
GA-2-98066"21650013200330002310016500115508250
GA-2-98088"222750182004550031850227501592511375
GA-2-9801010"228400
227205680039760284001988014200
